AGM Rattler-C V2 50-640 Thermal Clip-On

Core Features

The top Rattler-C V2: a 640 sensor and a 50 mm lens in front of the day scope already on your rifle, for hunters who want the detail and reach of a dedicated 640 thermal without giving up their glass. It mounts in front of an LPVO or low-power scope (1x to 6x works best) and runs a 640x512, 12 micron sensor with NETD under 20 mK at 1x, so your reticle and zero stay the same. It detects a 6 foot heat source to about 2,600 meters (2,843 yards). A single NE-4400 battery runs it for up to 9 hours, two batteries come in the box, and shot-activated recording saves the moments before and after each shot to 16 GB of memory. The included ADM Picatinny mount sits at 1.5 inch centerline height; mounting directly to the day scope objective needs a Front Q-R adapter, sold separately. 50 Hz refresh, Wi-Fi, IP67 waterproof, 1000 g recoil rating, and AGM's 5-year warranty.

Sub-20 mK 640 Sensor and 50 mm Lens

The 640x512 VOx detector has NETD under 20 mK and runs at 50 Hz, so detail holds on damp, low-contrast nights. The 50 mm F1.0 lens gives an 8.8 x 7.0 degree field of view and focuses from 10 meters to infinity. Optical magnification is 1x so the image through your day scope stays true, with digital zoom to 8x available when used as a handheld.

Display and Image Controls

A 1024x768, 0.39 inch OLED with 22 mm exit pupil and 10 mm eye relief for the day scope objective. Black Hot, White Hot, Red Hot and Fusion palettes, cold and warm scene modes, hot track, stadiametric distance measurement, defective pixel correction, and auto, manual or external flat field correction.

Recording and Wi-Fi

Video with audio and still capture save to 16 GB of built-in EMMC memory. Shot-activated recording captures each shot automatically. The Wi-Fi hotspot streams live video to a phone and transfers files through the AGM app.

Power

One removable, rechargeable 4400 mAh NE-4400 Li-ion runs up to 9 hours at 25 degrees C with the hotspot off; a second battery and charger are included. The USB Type-C port accepts a 5 V / 2 A power bank, and standby mode stretches a long sit.

Mounting and Durability

Ships with an ADM Picatinny mount (1.5 inch centerline). IP67 waterproof, rated for 1000 g / 0.4 ms recoil and -30 to +55 degrees C. The body measures 196 x 73 x 68 mm (7.7 x 2.9 x 2.7 inches) and weighs 0.55 kg (1.2 lb) without mount or battery.
