LEAP L3R Thermal Imaging Riflescopes

Core Features

A premium thermal imaging riflescope integrating laser rangefinding and ballistic calculation capabilities for enhanced targeting precision. The optical system features 3.2-9.6x magnification with supplementary 1-4x digital zoom and picture-in-picture functionality. Electronic zeroing with 0.3 MOA adjustment capability enables precise windage and elevation corrections. The scope includes photo and video recording with recoil-activated capture technology. Large zoom ring with throw lever facilitates intuitive magnification control. 32GB onboard storage accommodates extensive photo and video libraries, with offloading via USB cable and wireless streaming to smartphones through the LEAP companion app. Includes a cantilevered 30mm Picatinny-compatible scope mount.

Integrated Rangefinding and Ballistics

A built-in laser rangefinder provides accurate distance measurement to target locations. The system automatically calculates and displays critical ballistic data necessary for shot placement, accounting for environmental variables and ammunition characteristics. This integration eliminates the need for external ranging devices or manual ballistic calculations.

Advanced Thermal Sensor

The thermal imaging system utilizes a 384 x 288 resolution sensor with noise equivalent temperature differential performance below 20 milliKelvins and 50Hz refresh rate. These specifications ensure exceptionally clear, low-noise thermal imagery with fluid motion rendering. The 1920 x 1080 OLED display provides rich color reproduction and superior contrast.

Flexible Magnification System

The optical zoom mechanism delivers a range from 3.2x to 9.6x magnification. Users can supplement optical magnification with up to 4x digital zoom for extended-range observation. The picture-in-picture feature enables independent magnification of a secondary viewing window while maintaining full-frame situational awareness.

Reticle Customization Options

Users select from eight reticle patterns combined with six distinct image color palettes, providing 48 total configuration combinations. This extensive customization enables personalization based on lighting conditions and operational requirements.

Recording and Documentation

The scope records full audio-enabled video and captures still images. Recoil-activated recording automatically preserves footage from the moments preceding and following each shot. All content saves to 32GB of internal memory for later transfer via USB connection or wireless streaming.

Wireless Connectivity

Built-in Wi-Fi capability enables real-time streaming to compatible smartphones through the LEAP app. Wireless data transmission supports software updates and remote content management.

Control System Design

Integrated switches and dials manage multiple functions including electronic zeroing, photo/video activation, rangefinding activation, and settings adjustment. This unified control interface streamlines operation while maintaining comprehensive feature access during field use.

Precision Zeroing

Electronic zeroing with 0.3 MOA adjustment increments enables fine-tuning of windage and elevation settings for optimal accuracy across various shooting distances and ammunition configurations.

Power Management

A single 18650 rechargeable battery provides approximately 4 hours of continuous operational runtime. The replaceable battery design facilitates extended field use with backup power sources.

Environmental Protection

IP67 water and dust rating ensures reliable operation across challenging weather conditions including rain, fog, and moisture-rich environments.

Mounting System

The cantilevered 30mm Picatinny-compatible mount provides secure, stable attachment to standard rifle platforms with forward-positioned optical alignment.
