Pulsar Oryx LRF XG35 Thermal Monocular
Thermal Monocular
Core Features
A handheld 640 thermal monocular with a built-in laser rangefinder, built for long glassing sessions where battery life and durability matter as much as the image. The Oryx LRF XG35 pairs a 640x480, 12 micron sensor with an F35/1.0 lens for detection beyond 1,950 yards on a 6 foot target, shown on a 1024x768 AMOLED display, the highest resolution display in Pulsar's handheld line. Magnification runs 2.5 to 20x, the battery runs up to 12 hours, and the magnesium body is IP67 rated against water, dust and shock. Backed by Pulsar's 3-year warranty, extended to 5 years with registration.
640 XG Sensor
The 640x480 sensor at 12 microns runs at 50 Hz with NETD under 40 mK (sNETD under 20 mK), and the 1024x768 AMOLED display shows the full sensor resolution without scaling.
Optics
The F35/1.0 lens gives a 12.5 degree field of view at 2.5x base magnification, with 8x digital zoom to 20x for checking a distant heat source.
Laser Rangefinder
The built-in rangefinder confirms distance without reaching for a second device, so you know the yardage before you move.
Recording and App
Photo and video record at 960x600 to 64 GB of built-in memory. Dual-band Wi-Fi streams the live view to a phone through Stream Vision 2 and handles firmware updates.
Power
The 4900 mAh battery runs up to 12 hours at room temperature, a full night without a swap.
Durability
Magnesium alloy housing with an IP67 rating, fully waterproof, dustproof and shockproof, rated from -13 to 104 degrees F. A 1/4 inch tripod socket is built in.
Specifications
CORE CHARACTERISTICS:
| Category | Specification | Details |
|---|---|---|
| Thermal Sensor | Detector Type | Uncooled, 12 μm pixel pitch |
| Resolution | 640 x 480 | |
| NETD (Thermal Sensitivity) | <40 mK (sNETD <20 mK) | |
| Refresh Rate | 50 Hz | |
| Detection Range (6ft object) | 1,950+ yards | |
| Optics | Objective Lens | F35, F/1.0 |
| Magnification | 2.5x to 20x (8x digital zoom) | |
| Field of View | 12.5° | |
| Display | Display | AMOLED, 1024 x 768 |
| Rangefinding | Laser Rangefinder | Yes, built in |
| Recording & Connectivity | Video / Photo | 960 x 600, .mp4 / .jpg |
| Built-In Memory | 64 GB | |
| Wi-Fi | 802.11 b/g/n/ac, 2.4 / 5 GHz | |
| Apps | Stream Vision 2 | |
| Power | Battery | Li-Ion, 4900 mAh |
| Runtime | Up to 12 hours @ 22°C | |
| Durability | Operating Temperature | -13°F to 104°F |
| Environmental Protection | IP67 (waterproof, dustproof, shockproof) | |
| Warranty | 3 years, 5 years with registration | |
| Physical | Body | Magnesium alloy |
| Dimensions | 7 x 2 x 3 in | |
| Weight | 17.6 oz (with battery) | |
| Tripod Mount | 1/4 inch socket | |
| Identification | Model / UPC | PL77504 / 840284902061 |
Note: Detection range is not the same as identification range. For identification ranges and other questions, contact us directly.
